Description
Portable or Fixed Mount Patio Heaters – Schwank
A heavy-duty commercial-grade outdoor portable propane and fixed mount natural gas portable patio heater. These are low-cost options. The parasol gas heater is built with a durable stainless steel finish and offers an easy to ignite and adjust heat with a turn control.
Portable and fixed-mount commercial patio heaters
These 90” gas patio heaters are built on sturdy 4″ wheels and can easily be moved from one location to another and can be moved to a secure storage location. 32” wide at the base, these patio heaters are available in a portable unit [the base holds a 20/30lb propane tank] and a fixed unit, fueled from your natural gas line.
These Schwank heaters have a stainless steel enclosure and a sleek design to help blend easily into any restaurant design. The portable line is design certified by CSA International for use outdoors in accordance with current ANSI standards.
Applications
- Commercial patios with no roof or nearby walls
Dimensions and Specifications
| GAS PRESSURE |
|||||||||
| PORTABLE: | FINISH | DIMENSIONS | INPUT BTU/hr | FUEL | MIN | MAX | INLET | GAS SUPPLY | WEIGHT LBS. |
| 4005-CB | Stainless Steel |
90″ x 32″ | 38,000 | LP | 11″ w.c. | 14″ w.c. | QCC | 20 lb. cylinder | 60 |
| GAS PRESSURE | |||||||||
| FIXED-MOUNT: | FINISH | DIMENSIONS | INPUT BTU/hr | FUEL | MIN | MAX | INLET | GAS SUPPLY | WEIGHT LBS. |
| 4SN5-CB | Stainless Steel |
90″ x 32″ | 38,000 | NG | 5″ w.c. | 7″ w.c. | 1/2″ | Piped from central supply |
60 |
Parasol 4000 is design certified by CSA International for use outdoors in accordance with current ANSI standards.
Schwank warrants that the heater will operate as designed for wind conditions up to 10 MPH. Please note that adverse wind and weather conditions will reduce the effectiveness of any heating system.
WARNING:
